Compolam XRL 2000 Laminates - Metal-clad PEEK
Durable thermoplastic laminates that perform reliably in harsh environments

Compolam - space - no outgassing - PEEK has good radiation resistance
Compolam XRL 2000 - PCB for medical application - chemical resistant PCB - raditation resistant PCB - Xray transparant
Compolam XRL - de-icing heater circuit - high temperature PCB - electrical circuit in jet engine - wire harness - hydraulic fluid resitant material
Compolam XRL2000 - PEEK with steel - chemical resistant PCB - PCB material for oil and gas - deep hole drilling - electronics in oil and gas - corrosion barrier
Compolam XRL 2000 - PCB for harsh environment - defense - light weight wire harness - lightning strike protection - deicing heater

Traditional laminated materials break down or delaminate
when exposed to harsh working environments

Compolam XRL 2000 - high temperature PCB - high temperature heating circuit - high temperature shielding

What if your application requires operating at >200°C  (500°F) or is exposed to severe thermal shocks?

Traditional dielectric materials are typically designed to withstand 150 - 175°C for continuous operation and 2 - 4 °C/sec. temperature gradient

Compolam XRL 2000 - high chemical resistance PCB - high chemical resistant heater circuit - high chemical resistant shielding - very low moisture absorption

What if your application requires outstanding resistance to moisture and complex chemicals?

The properties of traditional dielectric materials and plastics can be affected by humidity, or when exposed to solvents, to acids or bases, to caustic or electrolytic fluids

Compolam XRL 2000 - radiation resitant PCB - radiation resistant heater circuit - radiation resistant shielding - X-ray transparancy

What if exposure to radiation is inherent to your application?

Gamma radiation causes heavy oxidation of traditional dielectric materials and plastics.  Their properties deteriorate rapidly.

Traditional materials may cause optical artifacts in X-ray applications

 For your most challenging and hostile conditions
Compolam XRL 2000 Laminates
are your choice

Key Features:

Up to 260°C continuous operating temperature

Chemically inert    -    No outgassing

Extreme low moisture absorption

Great resistance to gamma radiation

Halogen-free -  Inherent fire retardant

High dielectric breakdown    -    Recyclable

Applications:

(Flexible) Printed Circuit Board

Wire harness    -    (Flexible) Heater circuit

Corrosion protection   -    EMI-EMC Shielding

Actuators    -    Sensors    -    RFID tag

 Packaging    -    AFP laminate    -    Insulation

Compolam XRL 2000 - high temperature PCB - chemical resistant PCB - copper clad PEEK - LHT
Compolam XRL 2000 - high temperature flexible heater - polyimide heater circuit - flexible

Our expertise and manufacturing capabilities allow us to make the laminate that fits your application

  • What is PEEK ?
    PEEK, or Poly-Ether-Ether-Ketone is a semicrystaline thermoplastic. The melting temperature is 341°C (649°F). PEEK is famous for its extreme chemical resistance and is often used as a lightweight composite material to replace metal parts.
  • What thermoplastics are available?
    Compolam XRL 2000 laminates are based on PEEK (Poly-Ether-Ether-Ketone). This is a high-performance thermoplastic with excellent high temperature, chemical resistance and radiation resistance capabilities. Other high-performance thermoplastics are currently under development and supplied for customer-specific projects. If you have any specific requests, please contact us.
  • What metals claddings are available?
    Compolam XRL 2000 Laminates are typically cladded with ED copper. Other metal claddings are available on demand: - Stainless Steel - Nickel - Inconel - Titanium - etc. Please, tell us what you are looking for
  • Are the thermoplastic laminates reinforced?
    We offer both thermoplastic laminates: - XRL 2000: without glass reinforcement - XRL 2100: with glass reinforcement
  • What temperatures can XRL 2000 Laminates handle?
    Compolam XRL 2000 Laminates are based on PEEK (Poly-Ether-Ether-Ketone). - The melting point of PEEK is 343°C (650°F) - We have great experience with continuous operating temperatures for more than 3000 hours at 260°C (500°F) (and even up to 330°C (626°F) with an oxidation barrier) without delamination, even in harsh vibration conditions. - We have excellent experience with multiple thermal shocks (room temp. to 300°C) without degradation of the copper adhesion. Contact us for more detailed information.
  • What adhesive system is used in XRL 2000 laminates?
    Compolam XRL 2000 Laminates do not have an adhesive layer. This makes them more robust and thinner. Adhesives are typically the weakest layer in a metalized laminate.
  • Are the laminates available in rolls, tapes or sheets?"
    Our laminates can be available in rolls, tapes and/or panels
  • What dimensions are available for XRL 2000?
    The dimensions can be adjusted to your request. (*) Standard dimensions: Sheets : - 24" x 18" (610mm x 457mm) - 12" x 18" (305mm x 457mm) - 12" x 9" (305mm x 229mm) - A4 size (210mm x 297mm) Rolls: max 24" (610mm) wide (*) Note: Possible dimensions might be restricted by the available width of the raw materials and by the thickness or rigidity of the construction
